Chapter 3
Channel Plans
Using a channel plan, the SDA field unit memorizes the frequencies of active
channels on your system.
NOTE: Separate channel plans are required for:
• general measurements (tilt, level, and so on)
• reverse sweep
• loopback sweep
Changing the channel plan on the field unit has no effect on
the sweep. The headend unit’s channel plan is used by
default.
Before you begin, be sure that:
• You have completed the basic setup as described in:
• “Global Configuration” (Chapter 2, page 23)
• “Measurements Configuration” (Chapter 2, page 25)
• “Sweep Configuration” (Chapter 4, page 64)
• You are thoroughly familiar with the instrument’s functions, controls, and
indicators.
INTRODUCTION
