Channel Plans: Setting Channel Plan Parameters
40
3
See Also
½ For more information about these signal types, see the
Glossary at the end of this manual.
Channel Tuning Sequence
At the CHANNEL PLAN menu (Fig. 3.2), select Channel Tuning Sequence
and press the Enter key. The up and down diamond keys toggle between
Numeric Order and Frequency Order.
Select the item desired, press the Enter key again, then use the up or down
diamond keys to scroll to the next parameter.
Build Channel Plan
From the CHANNEL PLAN menu, select Build Channel Plan. The SDA unit
creates a channel plan by memorizing the active channels in the system,
and by identifying by default those that are not active.
CAUTION ! Be sure that the SDA is correctly connected to
the cable system at COAX IN.
NOTE: Channels < -10 dBmV will not be recognized as
active channels.
1. As prompted by the Edit Box, press the Continue soft key,
and the screen shown in Fig. 3-5, BUILD PLAN STEP 1,
appears.
