Specifications
346
B
Zero-Span Mode
Video BW: >1MHz, 100 kHz, 10 kHz, 100 Hz
Resolution BW: 2 MHz, 280 kHz, 30 kHz
Measurement BW
compensation: programmable 1 kHz - 99 MHz
Pulse measurement
accuracy: nominal level in 10 µs
+/- 2 dB from nominal in 5 µs (>1 MHz VBW,
280 kHz RBW)
Sweep times: 100 µs to 20 s (1, 2, 5 settings)
Intermodulation Distortion (CSO/CTB)
Range: ≥ 60 dB
Resolution: 0.1 dB
Reverse Transmitter
(Available only on SDA-5000 with OPT2)
Frequency range: 5 to 1,000 MHz
Output level: +20 to +50 dBmV, adjustable in 2dB
increments
Spectral purity: Hars -30 dBc; Spurs -35 dBc
Telemetry
Frequency range: 5 to 1,000 MHz
Modulation: FSK, 100 kHz deviation
Spectrum required: 1.0 MHz vacant bandwidth recommended
Spectral purity: Hars -30 dBc; Spurs -35 dBc
