Description and Basic Operation: Configuring the SDA-5000
22
2
to toggle between the Local and Remote traces to compare measurement
data so you can quickly determine if an ingress problem exists, and if it does,
you can isolate its source.
See Also
½ Chapter 8, PathTrak Field View (OPT3), discusses the
PathTrak Mode in detail.
This section describes the configuration options you access from the
CONFIGURE menu. Global, Measurements, and Diagnostic configuration
are discussed here in detail. Channel Plan, Sweep Receiver, and PathTrak
configuration are covered briefly in this chapter, and in detail in their
respective chapters later in the manual.
To call up the CONFIGURE menu shown in Fig. 2-6, turn the unit on and
then either
• Press the Nav support key (see Fig. 2-2), select the Files and Configure
tab, then the crossed-tool Config icon
or
• Press the Function and 3 ghi keys
NOTE: If the internal transmitter requires self-calibration,
you will see a prompt to perform a self-calibration of the
internal transmitter. See page 30 for instructions on how to
do this.
CONFIGURING THE SDA-5000
