SDA-5500/SDA-5510 Sweep Configuration: Forward Sweep Configuration (SDA-5500)
273
14
Use the up and down arrow keys or the numeric keypad to enter the sweep
insertion level (20-50 dBmV).
Include Audio Carriers
This selection allows the audio carriers to be excluded resulting in a faster
sweep. Use the up and down arrow keys to include (Ye s) or exclude (No)
audio carriers.
Enable or Disable Reverse Sweep
When Reverse Sweep is enabled, both Forward and Reverse sweeping can
be performed. Only Forward sweeping is possible when Reverse Sweep is
disabled.
NOTE: Reverse sweep should be disabled when there are
no field units being used with OPT1(Reverse Sweep). This
will optimize the update rate of the forward sweep. It should
also be disabled if you are using an SDA-5510 for reverse
sweeping.
Select the Frequency of the Reverse Telemetry Carrier
This is the frequency at which SDA-5000 units with the Reverse Sweep
option will transmit telemetry data. Optimally this will be in a portion of the
reverse frequency band with at least 1 MHz free, and at best case, in the
high end of the return band to avoid potential interference from ingress.
NOTE: The frequency of the reverse telemetry carrier
should be carefully selected such that it will not interfere
with any existing carriers on the reverse plant or be in the
roll-off.
Access Reverse Sweep Plans
Reverse sweep plans are used to define the frequencies at which sweep
points will be inserted by SDA-5000 units with the Reverse Sweep option. To
access reverse sweep plans, select the Reverse Sweep Plans option and
then press the Enter key.
