Description and Basic Operation: Printing Measurements and Files
33
2
This section describes the procedures for printing screens or files from your
field unit. Before printing, be sure the printer is properly attached.
NOTE: Interface the SDA-5000 to a PC with an SDA-to-
PC cable, P/N 1217-50-0158. The SDA-to-SDA interface
cable is P/N 1217-50-0149. The SDA-to-Printer interface
cable is P/N 1217-50-0159. These three cables are
different. Pin-outs and connector types are available by
calling Acterna Customer Service at the appropriate
number for your location as listed in Chapter 12
(page 209).
• To print any measurement mode screen, press the Function and Print
(1 abc) keys.
• To print a file, press the Nav support mode key and use the arrow keys to
select View mode. Use the soft keys or press the Function and Print
(1 abc) keys.
See Also
½ The “Global Configuration” section earlier in this chapter
discusses setting up your unit for printing to a serial or
parallel printer (page 23).
PRINTING MEASUREMENTS AND FILES
