Description and Basic Operation of the SDA-5500 and 5510: Using Auto Test
252
13
shows which of the parameters in the table above apply to each of the
location types.
Editing of location files is done by pressing the Edit soft key (Fig.13-26). The
optional fields will be enabled or disabled according to the location type
selected (see table above).
Use the up and down arrow keys to scroll to the desired parameter. Use the
up and down diamond keys or the numeric entry keypad to enter the desired
value. Once all the desired parameters have been edited, press the OK soft
key.
The Delete soft key is used to delete a specific location file.
How To Perform An Auto Test
The Auto Test mode provides automated FCC 24 hour testing capabilities.
Video and audio carrier levels will be measured for each enabled channel.
Additionally, the following can be selectively measured for each channel: C/
N, hum, and modulation.
Table 10-2 Parameters and Test Location Types
Parameter Trunk Head Extender Fiber Field
Area
✔✔✔✔
Amp ID
✔✔✔
Power Configuration
✔✔✔
Feeder Maker Config
✔✔✔
Trunk Termination
✔✔✔
Voltage Setting
✔✔✔
Reverse Pad
✔✔✔
Reverse Equalizer
✔✔✔
Forward Pad
✔✔
Forward Equalizer
✔✔
To Next Page
