Specifications
348
B
AC line (SDA 5000)
Charger input: 100-250 VAC 50 - 60 Hz, 0.5A
Charger output: Aux out: 16V @ 750 mA
Charge: 15V @ 750 mA
AC line (SDA 5500)
Charger input: 100 to 265 to 63 Hz ~ 100 VAC
47 to 63 Hz ~ 100 VA
Forward Transmitter (OPT 2)
(Available only on SDA-5500 and SDA-5000 with OPT2)
Frequency range: 5 to 1,000 MHz
Output level: +20 to +50 dBmV, adjustable in 2 dB
Spectral purity: Hars -30 dBc; Spurs -35 dBc
PathTrak Field View (Option 3)
(Not available on SDA-5510)
Update rate: 2x/second (remote trace); ~1x/second (local
trace)
QAM View Option (Option 4)
Modulation Type:
64/256 QAM, DVB-C, ITU-T J.83 Annex A (Option 4A)
64/256 QAM, DVS-031, ITU-T J.83 Annex B (Option 4B)
Measurable Input Range (Lock Range):
64 QAM: -20 to +50 dBmV
256 QAM: -15 to +50 dBmV
Frequency Tuning:
(Digital QAM mode): 50 to 860 MHz
Resolution: 50 kHz
