Chapter 14
SDA-5500/SDA-5510 Sweep
Configuration
This chapter tells how to connect to a headend for sweeping and details all
procedures involved in setup and use, for system commissioning and for
maintenance. It concludes with coverage of the history and theory of
sweeping.
The following sections show you how to connect the SDA-5500 to the
headend, how to set the proper levels and telemetry for forward sweep, how
to create a channel plan, and how to conduct the sweep.
Wiring Connections
Either of the configurations shown in Figures 14-1 and 14-2 will work for
SDA-5500 forward-only sweep.
INTRODUCTION
FORWARD SWEEP CONFIGURATION (SDA-5500)
