Section 4, EoCu Provisioning - Create an EVC
65K510DEP08-1A
4-23
NOTE
If
creating
an
EVC
with
the
same
S
‐
tag
as
the
management
traffic,
the
conflict
is
noted
in
the
status
of
the
EVC.
EVC Example
The
following
is
a
sample
output
of
the
show
interfaces
EVC
command
for
evc2010.
MyNV838>
show evc evc201
0
EVC evc2010
S-TAG
:
2010
Admin State
:
Enabled
EVC Status
:
Running -
Enabled
MEN-port
:
EFM-Group
1/0/1
CE-VLAN Pres
ervation :
Disabled
MyNV838#
