Section 2, Installation - Mount the Chassis
65K510DEP08-1A 2-7
Mount the Chassis
NOTE
Whenmountingthechassis,leavethemountingscrewslooseuntiltheSMIO3
andfanmodulehavebeeninstalled.
Thechassisisshippedwithtwomountingbracketsthatareusedtoinstallthechassiswith
eithera2‐inch,3.3‐inch,4.1‐inchor5‐inchfrontprojection.Eachbracketisattachedwithfive
screws,whicharesuppliedwiththechassis.RefertoFigure
2‐4formountinglocationsand
mountingbracketorientations.
Figure 2-4. Mounting Bracket Locations
2-Inch Front
Projection
3.3-Inch Front
Projection
4.1-Inch Front
Projection
5-Inch Front
Projection
