ADTRAN TA 5000 User Manual

Appendix G, BSM DS3/DS1 Layer 1 Tests - DS1 Test Configuration
65K510DEP08-1A G-5
1. FromtheEnableprompt,typeapplication,andpressENTERtoaccesstheApplication
prompt.
2. FromtheApplication prompt,starttheBERTbyperformingoneofthefollowing
commands:
•Type
test interface t3 <shelf/slot/port> remote pattern
<pattern_type>
,andpressENTER.
•Type
test interface t3 <shelf/slot/port> remote pattern
<pattern_type> loopback line timeout <0-9999>
,andpressENTERtostarta
DS3BERTtestandrequestaremoteloopback(atthecustomerequipmenttoward
theTotalAccess5000)oftheDS3.
NOTE
Valid<pattern_type>valuesarep215,p220,andp223.
3. FromtheApplication prompt,type
test interface t3 <shelf/slot/port>
insert-error
,andpressENTERtoinjectabiterrorintothepattern.
NOTE
•Injectingabiterrorintothepatternisoptional
NOTE
•TheDS3BERTtestcanbestoppedbytypingno test interface t3
<shelf/slot/port>,andpressENTER
DS1 Test Configuration
Thissectiondetailsthefollowinginformation:
•Remoteloopbackconfiguration
•Testadministrativefunctions
•Locallineloopbackconfiguration
•BERTtestconfiguration
Remote Loopback Configuration
Toconfiguretheunittorespondto(enable)ortoignore(disable)toremoteloopback
commands,completethefollowingsteps:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
interface t1 <shelf/slot/
port:channel>
,andpressENTERtoaccesstheT1InterfaceConfigurationprompt.
3. FromtheT1InterfaceConfigurationprompt,performoneofthefollowing:
•Type
remote-loopback <command_type>,andpressENTERtoprovisiontheport
torespondtoremoteloopbackcommands.
