ADTRAN TA 5000 User Manual

Section 7, EoF Provisioning - Create an EVC Cross Connect
65K510DEP08-1A 7-7
Provisioning Steps
Thisprocessestablishesaconnectionbetweenthephysicalportandthevirtualnetwork.
TocreatetheEVC,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtogettotheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
evc <evc_name>,andpressENTER.
3. FromtheEVCI n terface Configurationprompt,type
s-tag <1-4094>,andpressENTER
tosettheS‐tagofthe EVC.
4. FromtheEVCI n terface Configurationprompt,type
connect men-port default
ethernet interface 1/A/1
,andpressENTERtoconnecttheactiveSMNet1interface
totheEVC.
NOTE
Thecon ne ctmen‐portgigabit‐ethernetcommandentryappliestotheactive
GigESM,independentofwhichGigE SMisactuallyspecified,inanAc tive/
Standbyconfiguration.
5. FromtheEVCI n terface Configurationprompt,type
connect men-port gigabit-
ethernet <shelf/slot/group>
,andpressENTERtoconnecttheGE8‐PorttotheEVC.
6. FromtheEVCI n terface Configurationprompt,type
no shutdownandpressENTERto
enabletheEVC.
7. FromtheEVCI n terface Configurationprompt,type
endandpressENTERtoreturntothe
Enableprompt.
ELAN Definition
AnEmulatedLocalAreaNetwork(ELAN)isasingleshelfapplicationthatsupportssingle
taggedMEPsforEthernetOAM.DoubletaggedMEPsforEthernetOAMwhendoingELAN
arenotsupported.AnELANEVCcanbeprovisionedwithendpointsaccessedfromanyEoF
accessmodule.MixedaccessELANEVCsarealso
possible.
Provisioning Steps
ToprovisionanELAN,completethefollowing:
1. FromtheEnableprompt,type
config term,andpressENTER.
2. FromtheGlobalConfigurationprompt,type
evc WORD,andpressENTER.
3. FromtheEVCI n terface Configurationprompt,type
connect men-port gigabit-
ethernet <shelf/slot/port>
,andpressENTER.
UsethiscommandtoconfigurewhichGigE8‐PortLMporttheselectedEVCisapplied
to.
4. FromtheEVCI n terface Configurationprompt,type
mac-switched,andpressENTERto
enableMACSwitching.
5. FromtheEVCI n terface Configurationprompt,type
endandpressENTERtoreturntothe
Enableprompt.
