Section 6, EoTDM Provisioning - Provisioning Summary
65K510DEP08-1A 6-3
Provisioning Summary
TocreateadatapathfromtheGigESMportontheTotalAccess5000toanEthernetporton
theNetVanta800,completethefollowing:
1. ProvisiontheDS3EFM4‐PortorDS3EFM3‐PortLineModule.
Formoreinformation,referto“ProvisiontheLineModule”onpage 6‐4.
2. Create
anEFMbondinggroupattheGigESMthatbondsasetofDS3portsontheDS3
EFMlinemoduletogether.
ThebondinggroupactsasthedataflowaccesspointtotheNetVanta800andisthepath
downwhichthemanagementconfigurationispushed.
Formoreinformation,refer
to“CreateanEFMBondingGroup”onpage 6‐6.
3. CreateanEthernetVirtualCircuit(EVC)attheTotalAccess5000thatconnectstheEFM
grouptotheGigabitEthernetportoftheGigESM.
ThiscreatesthemappingoftheS‐taggeddata.Thisaccomplishesthefollowing:
•TheGigESMknowswhere
tosendthetaggedtrafficcominginfromthegigabit
networkport
•TheGigESMpushestheavailabletagstoeachEFMbondinggroupandtoeach
NetVanta800forthelocalNetVanta800provisioning
4. LogontotheNetVanta800.
Formoreinformation,referto“LogOntotheNetVanta800”
onpage 6‐16.
5. CreatetheEVCattheNetVanta800.
TheEVCisalogicalconnectionpointintotheEFMgroup.
•MultipleEVCscanbecreatedforagivenEFMgroup.
•FortheNetVant a,theshelfisalways1andtheslotisalwayszero.
Formoreinformation,referto“CreateanEVC”onpage 6‐17.
6. CreateamapattheNetVanta800thatinformstheunittoswitchdatafromagivenUser
toNetworkInterface(UNI),ataminimum,to
aparticularEVC,andviceversa.
Formoreinformation,referto“CreateanEVCMap”onpage 6‐20.
7. ProvisionMACAddressLimitingandAging.
Forformoreinformation,referto“ProvisionMACAddressLimitingandAging”on
page 6‐27.
8. Disableanyunusedinterfaces.
Formoreinformation,referto“DisableUnusedNetVanta800
Interfaces”onpage 6‐28.
