Section 2, Installation - Install the Fan Module and Fan Filter
65K510DEP08-1A 2-5
Install the Fan Module and Fan Filter
Thissubsectiondetailsthefollowing information:
•DescriptionoftheFanModule
• Installationstepsforinstallingthe FanModuleandFanFilter
Fan Module Description
TheFanModuleconsistsofasheetmetaltraytha tholdsfourfansratedatanominal–48VDC.
TheFanModuleismountedfromthefrontoftherackandisinstalledintothetopslotofthe
TotalAccess5000Chassis.TheFanModuleisdesignedtoprovideforced
airventilationto
coolafullypopulatedTotalAccess5000Chassis.
Powerissuppliedtothe FanModulethroughtwoindependentcircuitsthatarecontrolledasa
group.Eachcircuitsuppliespowertotwofans,whichareconnectedinparallel.Whenfully
inserted,theFanModuleconnectstotheSMIO3.
TheSMIO3routespowerandserialcommu‐
nicationsfromtheswitchmoduletotheFanModule.Thefanmicroprocessorsamplesthe
speedofeach fanand reportsanalarmconditionforfanfailureoreminentfanfailure.
Installation Steps
ToinstalltheFanModule,completethefo llowing:
1. PushtheFanModulefirmlyintothetopslotofthechassis(seeFigure2‐2).
Figure 2-2. 23-Inch Fan Module Installation
2. Usethetwothumb‐screwsonthelowerleftandrightsideoftheFanModuletosecure
themoduletothechassis.
