ADTRAN TA 5000 User Manual

Appendix L, RPR Provisioning - Remote Terminal (RT) Provisioning
65K510DEP08-1A L-9
Provision the RPR Line Module
OncetheRTGigESMisprovisioned,thefollowingfeaturesoftheRPRLineModulemustbe
set:
•ProvisiontheTiming
•ProvisiontheHub/Spoke
•ProvisionIGMPMulticastVLAN
Provision the Timing
TheactiveRPRLineModulemustbeprovisionedwithLoopAbeingWestandLoopBbeing
East.ToprovisiontheRPRtiming,completethefollowing:
1. FromtheRPRLineModulemenu,select
Provisioning,andpressENTER.
2. FromtheProvisioningmenu,select
Timing,andpressENTER.
3. FromtheTimingConfigurationmenu,press
E.
4. FromtheTimingConfigurationmenu,selectSetTimingtoLoopB,andpress
ENTER.
5. FromtheTimingConfigurationmenu,press
W.
6. FromtheTimingConfigurationmenu,selectSetTimingtoLoopA,andpress
ENTER.
Provision the Hub/Spoke
RingsoriginatingataCOTNoderequirenoprovisioning.
NOTE
•IfanRPRring originatesataRemoteTerminal,thentheHub/SpokeMode
mustbesettoHubontheoriginatingNode.
•TheCOTNodeautomaticallysetstoHubMode.
