Total Access 5000 Business Services Deployment Guide
3-12 65K510DEP08-1A
Provision LACP
WhenconnectingtheGigESMtotheprovidernetworkinterfaceelement(normallyaswitch
orarouter),multipleconfigurationoptionscanbeused.ThecurrentBSMapplication
connectstotheexternalswitchwithasingleSwitchModuleport(NET1)fromeachSwitch
Module,usingLinkAggregationControlProtocol(LACP)to
conveyActive/Standbystatusof
eachGigESMport.
NOTE
Themaximumdatarateforthe networkinterfaceisstill1Gbps.Theuseof
LACPisindependentofusinglinkaggregationtoobtaingreaterthan1Gbps
networkconnection.ThisLACPuseisoftencalledhot‐standbyLACP.
Table3‐5displaysthethreeLACPmodes.
ToprovisionforLACP,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
interface gigabit-ethernet 1/A/1,
andpress
ENTERtoaccessthe GigE SMinslotAandtheNet1Configurationprompt.
NOTE
IfslotBistheactiveSM,use1/B/1forthe<shelf/slot/port>syntax.
3. ProvisiontheLACPModebyperformingoneofthefollowingcommands:
•Type
lacp mode active,andpressENTERtosettheportLACPmodetoactive
•Type
lacp mode passive,andpressENTERtosettheportLACPmodetopassive
•Type
no lacp mode,and pressENTERtosettheportLACPmodetodisabled
Table 3-5. LACP Modes
Command Description
lacp mode active
TheGigESMalwayssendsLACPpacketsalongtheconfiguredlinks.
lacp mode passive
TheGigESMwillnotsendLACPpacketsuntilithasfirstreceivedan
LACPpacket.
no lacp mode
LACPisdisabledforthisport.
