ADTRAN TA 5000 User Manual

Appendix F, NetVanta Examples - EVCs
65K510DEP08-1A F-5
Admin State
Thisattributeistheuser‐configurablestateoftheEVC.TableF‐4liststhe availableoptions.
MEN Port
ThisattributeisthephysicalinterfaceconnectedtotheMEN.Thepossibleoptionsconsistof
theEthernetport(s)andbondinggroup(s)availableonthespecificproduct.Intypicalconfig‐
urations,theMENportisspecifiedasabondinggroup.OneormoreMENportscanbe
directlyconnectedtoanEVC.
AconnectedMENporthasanassociatedstatusthatdetermines
ifitcanbeusedbytheEVCtotransmit/receivetraffic.Thisstatusisread‐onlytoanEVCand
iscontrolledbyexternalprocesses(forexample,LinkOAMorEVCAdvertisement).Ports
disallowedbyexternalprocessescannotbeusedduring
thevalidationoftheconfigurationof
anEVC.
S-tag
ThisattributeistheVLANIDassociatedwiththeEVCs‐tag.TheEVCVIDissetusingthes‐
tagcommand.Ifthealiasspecifiedduringcreationisnumeric,thes‐tagwilldefaulttomatch.
List of Connected EVC Maps
ThisattributelistsallEVCmapsconnectedtotheEVC,eachwithanassociatedstatus.EVC
mapslistedas“Running”cantransmit/receiveEVCtraffic.
NOTE
NotallEVCmapsarerequiredtobeinthe“Running”statefortheEVCtobe
successfullytransportingtraffic.
CE-VLAN Preservation
ThisattributecontrolswhethertopreservetheCE‐VLANtagwithintheEVC.Thisoption
mustbeenabledifmultipleCE‐VLANsareforwardedtotheEVC(RefertoRule9onpage F‐
2).TableF‐5liststheavailableoptions.
Table F-4. EVC State Options
Option Definition
Enabled TheEVCisinservice,andtheprovisioningisappliedifthecon‐
ditionsarevalid.
Disabled TheEVCisnotinservice,andtheprovisioningisnotapplied.
