Total Access 5000 Business Services Deployment Guide
C-8 65K510DEP08-1A
Create a MEP and Enable CCMs per MEP
TheNetVantaNCTE allowsMEPstobecreatedonthefollowinginterfaces:EFM‐group,
Ethernet,andGigabit‐Ethernet.TocreateaMEP,typetheappropriatecommandattheGlobal
Configurationprompt:
•
interface efm-group 1/0/1
• interface ethernet 1/0/x (for ethernet port x)
NOTE
MorethanoneEFM‐groupcanexist,butnotagainsttheTotalAccess5000.
•
interface gigabit-ethernet 1/0/1
NOTE
Gigabit‐portsarenotpresentonallNetVanta800‐seriesproducts.
TocreateaMEPandenabletheCCMspertheMEP,completethefollowingprocedure:
NOTE
EFM‐groupMEPsshouldonlybecreatedwithComp onent1MAs.Ethernet
andGigabit‐EthernetMEPsshouldonlybecreatedwithComponent2MAs.
1. FromtheInterfaceprompt,aMEPcanbecreatedoreditedifpreviouslycreatedbytyp‐
ing
ethernet cfm mep <MEPID> <MD_name> <MA_name> [up|down],andpress
ENTER.
UsetheMEPIDofthelocalMEP,theMDName,andtheMANameitistooperatein.
2. Enablecontinuitycheckmessages(CCMs)fortheMEPbytyping
ccm-enabled,and
press
ENTER.
3. EnabletheMEPbytyping
no shutdown,andpressENTER.
4. Type
exit,andpressENTER toreturntotheGlobalConfigurationprompt.
NCTE Ethernet OAM Example Using Component 1
Inthefollowingexample,theuseriscreatingalevel5MDbetweentwoendpoints(NCTEA
andNCTEB)andasingleMAoperatingontheProviderVID1010.NCTEAhasaMEPwith
aMEPIDof2000andNCTEBhasaMEPwithaMEPIDof2001.
TheCCMintervalisnot
explicitlyconfiguredsothedefaultCCMintervalof1‐secondwillbeused.
NCTE A Configuration
ethernet cfm
ethernet cfm domain char-string MD_5 level 5
association char-string MA_1010
remote-mep 2001
