ADTRAN TA 5000 User Manual

Total Access 5000 Business Services Deployment Guide
7-10 65K510DEP08-1A
Provisioning Steps
TocreateanEVC,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
evc WORD,andpressENTER tocreatean
EVC.
TheWORDattributeisanarbitrarystringthatisusedtoidentifytheEVCwithinthe
MEN.ThevaluemustbeuniqueacrossallEVCsdefinedintheNetVanta8044,andis
intendedformanagementandcontrolpurposes.Thevalueisnotcarriedinanyfieldin
theEthernetframe.
ThiscreatestheEVCandenablestheEVCConfigurationprompt.
Configure the EVC
TheMENportandS‐tagmustbeconfiguredfortheEVC.ToconfiguretheMetroEthernet
portandS‐tag,completethefollowingprocedure:
1. FromtheEVC Configurationprompt,type
connectmen-port gigabit-ethernet 1/
0/1
,andpressENTER tosettheMEN‐portastheGigabitEthernetportastheuplinkofthe
NetVanta8044.
Thisattributeistheinterfa c e connectedtotheMEN.Thepossibleoptionsconsistofallof
theEthernetport(s)availableontheNetVanta8044.
2. FromtheEVCConfigurationprompt,settheS‐tagbytyping
s-tag <0-4094>,and
press
ENTER.
ThisattributeistheVLANIDassociatedwiththeEVCtag.
NOTE
TheNetVanta8044S‐tagmustmatchtheS‐tagprovisionedintheTotalAccess
5000forthisEVCorEoFcircuit.
3. Bydefault,CEVLANPreservationisenabled.Todisable,type
no preserve-ce-vlan,
andpress
ENTER.
IfCEVLANPreservationisenabled,theNetVantapreservesthecustomer’sVLANtag
fortrafficenteringtheNetVanta.Itstackstheserviceprovidertagontopofthecustomer
tag.Ifitisdisabled,thecustomerVLANtagisstrippedbeforetheserviceprovidertagis
addedtothetraffic.
4. Bydefault,thenewEVCisdisabled.EnablethenewEVCbytypingno shutdown,and
press
ENTER.
5. Type
exitandpressENTERtoreturntotheGlobalConfigurationprompt.
6. Type
exitandpressENTERtoreturntotheEnableprompt.
7. Tosavethechangesinnon‐volatilememory,type
copy running-config startup-
config
,andpressENTER.
8. ViewthenewEVCbytypingshow evc WORD,andpressENTER.
