ADTRAN TA 5000 User Manual

Section 4, EoCu Provisioning - Create an EVC Map
65K510DEP08-1A 4-25
Provisioning Steps
Tocreatethemap,completethefollowingprocedure:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
evc-map WORD,andpressENTERtocreate
themapandenterthemapconfigurationmode.
Thisattributeisanarbitrarystringthatisusedtoidentifythemap.Thevaluemustbe
uniqueacrossallmapsdefinedintheproductandisintendedformanagementand
controlpurposes.Thevalueisnotcarriedinanyfield
intheEthernet frame.
Configure the Map
TheUsertoNetworkInterface(UNI)andtheEVCmustbeconfiguredforthemap.Amap
bindstheUNItraffictotheEVC.Toconfigurethemap,completethefollowingprocedure:
1. FromtheEVC‐MapConfigurationprompt,settheUNIbytypingeither
connect uni
ethernet
orconnectuni gigabit-ethernetfollowedbytheportnumberin1/0/
port
format,andpressENTER.
2. FromtheEVC‐MapConfigurationprompt,connectthenewmaptotheEVCbytyping
connect evc WORD,andpressENTER.
ThisattributeisthenameoftheEVCassociatedwiththemapandmustbespecified.
3. Inaddition,thefollowingattributesforthemapcanbeset:
a. Ifdesired,type
match broadcast,match multicast,and/or match unicast.
Toremoveanattributetype
no match broadcast,no match multicast,orno
match unicast
.
b. CEVLANID:ThisaddsthecustomeredgeVLANIDtothematchcriteriaofthe
map.Tosetthisvalue,type
matchce-vlan-id <0-4094>.Toremovethis
attributefromthematchcriteria,type
no match ce-vlan-id.
c. CEVLANPriority:ThisaddsthecustomeredgeVLANprioritytothematch
criteriaofthemap.Tosetthisvalue,type
matchce-vlan-pri <0-7>.Toremove
thisattributefromthematchcriteria,type
no match ce-vlan-pri.Arangeof
valuescanbespecifiedaspartofthiscommand.
d. Discard:Ifthisvalueisset,theNetVantadiscardsalltrafficthatmatchesthemaps
matchcriteria.Toenablediscardingtraffic,type
connect discard.Todisable,
type
no connect discard.Thisconnectiontakestheplaceoftheconnectionto
theEVC.
NOTE
IfthemapwaspreviouslyconnectedtoanEVC,itwillhavetobereconnected
aftertheno connect discardcommandisused.
e. DifferentiatedServicesCodePoint(DSCP):ThisaddstheInternetProtocolDSCPof
thecustomertraffictothematchcriteriaofthemap.Tosetthisvalue,type
match
dscp <0-63>
.Toremovethisattributefromthematchcriteria,typeno match
dscp
.ArangeofDSCPvaluescanbeenteredforthiscommand.
