Total Access 5000 Business Services Deployment Guide
2-22 65K510DEP08-1A
toaTotalAccess5000SwitchModule.SmallForm‐factorPluggable(SFP)cagesareprovided
forinputsonthefrontpanelofeachmoduleformaximumflexibilityoftheinterfaces.
CAUTION
!
Duetocompliance certificationrequirements, only SFPs supplied by
ADTRANcanbeusedwiththeGE4‐PortLineModule.ADTRANcannot
certifysystemintegritywithotherSFPs.
NOTE
•A LMIO2‐CH64Bmustbeinstalledpriorto installingtheGE4‐PortLine
Module.
•Forredundantconfiguration,theTotalAccess5000LMIO2RearPanelmust
beinstalled prior toinstalling theGE4‐Port LineModule.In anon‐
redundantconfiguration,theTotalAccess5000I/OBlankPanelmust
be
installedpriortoinstallingtheGE4‐PortLineModule.
RPR Line Module Description
TheRPRLineModuleprovidesanopticalringtransportoptionfortheTotalAccess5000.
TheRPRLineModuleprovidesuplinkanddownlinkconnectivityfortheTotalAccess5000
bywayofafiberring.AnRPRringprovidesthesametypeofClassofService(CoS)‐aware
connectivityasother
uplinkanddownlinkportsintheTotalAccess5000network,and
supportstransportofallTotalAccess5000services,signaling,andtimingtootherTotalAccess
5000sstationedonthering.
TheRPRLineModulesworkinpairs,witheachLineModuleprovidingeitheranEastora
Westspaninterface.
ThepairofRPRLineModulesshouldbeinadjacentslotsofthechassis,
withthelower,oddnumberedslotprovidingtheWestinterface,andthe higher,even
numberedslotprovidingtheEastinterface.
CAUTION
!
Duetocompliancecertificationrequirements,only3.125GbpsSFPssupplied
byADTRANaretobeusedwiththeRPRLineModule.ADTRANcannot
certifysystemintegritywithotherSFPs.
NOTE
TheLMIO2RearPanelmustbeinsta lled intheslotsonthebackoftheTotal
Access5000Chassisthatcorre spondtothe slotsinwhichtheRPRLine
Moduleswillbeinstalled;theLMIO2mustbeinstalledpriortoinstallingany
RPRLineModule.
PriortoinstallingtheRPRLineModule,installanADTRANapprovedopticalSFPmodule
intotherequiredSFPport.TheSFPmustbecapableofrunningat3.125Gbpsline rateto
supporta2.5Gbpsdatarate.
