Section 3, Common Provisioning - Provision the GigE SM
65K510DEP08-1A 3-7
3. Typeend,andpressEntertoreturntotheEnableprompt.
Provision the Network Ports
Toconfigurethenetworkportadministrationstates,completethefollowingprocedure:
Thisisasinglenodesetup,thereforeNetworkPort2willbesettotheOutof
Service‐Unassignedstate.Thispreventsanyunnecessaryalarmsforthe
unusednetworkport.
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
interface gigabit-ethernet 1/A/1,
andpress
ENTERtoaccessthe slotA,Net1Configurationprompt.
3. Type
no shutdown,andpressENTERtosettheporttoInService.
4. Type
interface gigabit-ethernet 1/A/2,andpressENTERtoaccesstheslotANet2
Configurationprompt.
5. Type
shutdown,andpressENTERtosettheporttoOutofService,Unassigned.
6. Type
exit,andpressENTERtoreturntotheGlobalConfigurationprompt.
7. Type
interface gigabit-ethernet 1/B/1,andpressENTERtoaccesstheslotB,Net1
Configurationprompt.
8. Type
no shutdown,andpressENTERtosettheporttoInService.
9. Type
interface gigabit-ethernet 1/B/2,andpressENTERtoaccesstheslotB,Net2
Configurationprompt.
10. Type
shutdown,andpressENTERtosettheporttoOutofService,Unassigned.
11. Type
end,andpressENTERtoreturntotheEnableprompt.
TheGigESMNET 1LEDshouldbegreen.Ifnot,performphysic allayer
diagnostics.
