ADTRAN TA 5000 User Manual

Section 2, Installation - Install the Front Panel Modules
65K510DEP08-1A 2-19
EFM Bonding Protection Module Description
TheEFMProtectAccessModuleprovidesEFMbondingengineprotectionforanyEFM
SHDSLorDS1EFM(1187802L1)accessmoduleinstalledinaTotalAccess5000system
beginningwithSystemRelease3.2.ThesemodulesmustsupportEFMbondingandhavebeen
cross‐slotprovisioned.
Install the EFM Bonding Protection Module
NOTE
ADTRANrecommendsinstallingtheEFMProtectAccessModulein slot11
or21oftheTotalAccess5000chassis.
ToinstalltheEFMProtectAccessModule,completethefollowingsteps:
1. PulltheejectorlatchesontheEFMProtectAccessModule,locatedontheupperand
lowerleft‐handsideoftheEFMBondingProtectionModulefrontpanel,fromtheclosed
positions.
2. Holdthe
EFMProtectAccessModulebythefrontpanelwhilesupportingthebottom
edgeofthemodulewiththeejectorlatchesopenedtoengagethechassis.
3. AligntheEFMProtectAccessModuleedgestofitinthelowerandupperguidegrooves
ofthemoduleslot.
4. SlidetheEFMProtectAccessModule
intothemoduleslot.Applysimultaneousthumb
pressureatthetopandbottomofthemodule(totherightoftheejectorlatches)toensure
thatthemoduleisfirmlyseatedagainstthebackplane.
5. SecuretheEFMProtectAccessModuleinplacebyrotatingtheejectorlatchesintothe
lockedpositions.
6. Install
oneofthefollowingAMIO1BlankPanelsontherearoftheTotalAccess5000
ChassisdirectlybehindtheEFMProtectAccessModule:
•P/N1187925L1isusedwiththeTotalAccess5000non‐shield ed chassis(1187001L1)
•P/N1187925G1isusedwiththeTotalAccess5000shieldedchassis(1187001G1)
Afterinstallationiscomplete,
theEFMProtectAccessModuleperformsaseriesofinitial‐
izationandself‐tests.Oncetheseriesofself‐testsarecompleted,thefrontpanelLEDsreflect
thetruestateofthehardware.
