Section 2, Installation - Install and Connect the Rear Panel Components
65K510DEP08-1A 2-11
Install and Connect the Rear Panel Components
ThissubsectiondetailstheconnectionandinstallationoftheTotalAccess5000rearpanels.
Connect the SMIO3
Theplasticguardthatcoversthewire‐wrapterminalsontheSMIO3isasafetyfeaturethat
preventspersonnelandequipmentfromcontactingexposedvoltages.
TheSMIO3isalreadyinstalledbutmustbeconnected.
Toremovetheguard,completethefollowingprocedure:
1. Usinga#1phillips‐headscrewdriver,removethethreescrewsthatsecuretheguard.
2. CarefullyremovetheguardbypullingitstraightfromtheSMIO3.
Toreinstalltheguard,reversethepreviousprocedures.
Inputandoutput
connectorsontheSMIO3consistofthefollowing:
• CommunicationsInterfacePorts–PhysicalinterfacestotheSCM,consistingofRS‐232‐
compatibleportsforAdminandNetworkManagementfunctions,andanEthernetLAN
forManagementfunctions
•TerminalBlockConnections–Labeledblocksofwire‐wrapterminalsforalarms,alarm
cutoff,
externalvoltage,clockfunctions,testbus,andshelflinkingfunctions
RefertotheTotalAccess5000SwitchModuleI/O3(SMIO3)Installationand
MaintenancePractice(P/N61187051G1‐5)fordetailedinformation.
AMIO1 Blank Panel
TheAMIO1coversonemoduleslotontherearoftheTotalAccess5000Chassis.
Install the AMIO1 Blank Panel
ToinstalltheAMIO1Blank Panel,completethefollowingprocedure:
1. PositiontheAMIO1Blankontherearalignmentpinsonthebackofthechassisoverthe
appropriateslot.
1. UsingtheCaptivePanelScrews,securetheAMIO1Blank totherearofthechassis.
AMIO2-CH50P Rear Panel
TheAMIO2‐CH50Pcoverstwomoduleslotsontherearofthechassis.TheAMIO2‐CH50Pis
designedtoholdtwostandardentry50‐pinmalechampconnectorcables.Forstandardentry,
thecableexitsthe90°connectorhoodonthepin1endofthemalechampconnector.
