Total Access 5000 Business Services Deployment Guide
C-12 65K510DEP08-1A
Create a MIP on a VLAN
MIPsarecreatedinthedefaultdomainpertheMIPrulessetperVLAN.ForaVLANtobe
addedtothedefaultdomain,theEVCfortheVLANshouldbecreatedbeforethefollowing
stepsareperformed.
OncetheVLANhasbeenaddedtothedefaultdomain,createtheMIP
byperformingthe
followingsteps:
1. FromtheGlobalConfigurationprompt,type
ethernet cfm default-domain toenter
theDefaultDomainConfigurationprompt.
2. FromtheEthernetOAMDefaultDomainConfigurationprompt,type
component 1
vlan <1-4094>
toentertheComponentConfigurationprompt.
3. FromtheEthernetOAMDefaultDomainComponentConfigurationprompt,type
level
<0-7>
tosetthedefaultlevelofthecomponent.
4. Type
mip-allowed anytoallowMIPstobecreatedontheVLAN.
NOTE
TheMIPiscreatedatthelowestlevelbetweenthelevelatwhichthedomain
wascreatedandthedefaultdomainlevel.Theexamplecommandsabove
createdthedomainatlevel6,and thedefaultdomainwassettolevel4,thus,
theMIPiscreatedatlevel4.
MIP Creation Example
ThefollowingexampledisplaysanadditionalMIPcreatedonVLAN200.
Switch(config)#ethernet cfm default-domain
Switch(config-ecfm-def-domain)#component 1 vlan 200
Switch(config-ecfm-def-comp)#level 4
Switch(config-ecfm-def-comp)#mip-allowed any
Create a Gigabit-Ethernet MEP on the Total Access 5000
Tocreateanetwork‐facingMEPattheGigabit‐EthernetnetworkinterfaceoftheTotalAccess
5000,completethefollowing(assumestheMDandMAhasbeencreated):
1. FromtheGlobalConfigurationprompt,type
interface gigabit 1/<active_SM>/1
toentertheGigabit‐EthernetInterfaceconfiguration.
2. FromtheGigabitEthernetInterfaceConfigurationprompt,type
ethernet cfm mep
<mepid> <domain_name> <domain_association> down
tocreatetheMEP.
3. FromtheEthernetOAMMEPConfigurationprompt,type
no mep-shutdowntoenable
theMEP.
4. FromtheEthernetOAMMEPConfigurationprompt,type
exit,andpressENTERto
returntotheGigabitEthernetInterfaceConfigurationprompt.
5. FromtheGigabitEthernetInt erfaceConfigurationprompt,type
exit,andpressENTERto
returntotheGlobalConfigurationprompt.
