Total Access 5000 Business Services Deployment Guide
7-6 65K510DEP08-1A
Create an EVC Cross Connect
Thissubsectiondetailsthefollowing information:
• DefinitionofanEVC
•GuidelinesforcreatinganEVC
•StepsforcreatinganEVC
EVC Definition
AnEVCisalogicalenti tythatprovidesameansforconnectingtwoendpointsintheTotal
Access5000andprovidesapathforEthernetframeswithaparticularVLANIDwithinthe
TotalAccess5000. TheEVCcross‐connectstwoormoreendpointsandprovidesthe
mechanismbywhichan
S‐tagpathiscreatedinthesystem.TheS‐tagcorrespondstothe
VLANID.
IntheTotalAccess5000,customertrafficswitchesthroughoutthesystemviaS‐tags
(outermostVLANtagonanEthernetpacket).Downstreamtrafficentersthesystemthrough
thenetworkportsontheGigESMand
isS‐tagswitchedtotheappropriateslot.TheGE8‐Port
LMthendecideshowtosendthattraffictothecustomer.Upstreamtrafficisswitchedtothe
networkinasimilarmanner.
NOTE
If the NetVanta 8044 management VLAN differs from the GigE SM
managementVLAN,createanEVCfortheGigESMtopasstheNetVanta
8044managementtraffic.Whencre atingacrossconnect,setupthecross
connectwithanS‐tagequaltothe NetVanta8044managementVLAN,
pointingtotheappropriateappropriateGigE8‐PortLMport.
EVC Cross Connect Guidelines
Whencreatingacross‐connect,enforcethefollowingguidelines:
•AnEVCcannotbepartofanothercross‐connect
• EachEVCmusthaveauniqueS‐tag
Table7‐3displaystheavailableS‐tagsintheTotalAccess5000.
Table 7-3. Available S-tag Range
S-tag Function
0,1,4095 Reserved
2–4094 EVPLsandInbandManagementVLAN
3072 InternalManagementVLAN(Default)
