Section 6, EoTDM Provisioning - Create an EVC Map
65K510DEP08-1A 6-21
Provisioning Steps
Tocreatethemap,completethefollowing:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
evc-map WORD,andpressENTERtocreate
themapandenterthemapconfigurationmode.
Thisattributeisanarbitrarystringthatisusedtoidentifythemap.Thevaluemustbe
uniqueacrossallmapsdefinedintheproductandisintendedformanagementand
controlpurposes.Thevalueisnotcarriedinanyfield
intheEthernet frame.
Configure the Map
TheUsertoNetworkInterface(UNI)andtheEVCmustbeconfiguredforthemap.Amap
bindstheUNItraffictotheEVC.Toconfigurethemap,completethefollowing:
1. FromtheEVC‐MapConfigurationprompt,settheUNIbytypingeither
connect uni
ethernet
orconnectuni gigabit-ethernetfollowedbytheethernetportnumber
in
1/0/portformat,andpressENTER.
TheWORDattributeisthephysicalinterfaceconnectedtothecustomerequipment.The
possibleoptionsconsistoftheEthernetport(s)andbondinggroup(s)availableonthe
NetVanta800.Intypicalconfigurations,thespecifiedoptionisanEthernetport.
2. FromtheEVC‐MapConfigurationprompt,connectthenewmaptotheEVC
bytyping
connect evc WORD,andpressENTER.
ThisattributeisthenameoftheEVCassociatedwiththemapandmustbespecified.
3. Inaddition,thefollowingattributesforthemapcanbeset:
a. Ifdesired,type
match broadcast,match multicast,and/or match unicast.
Toremoveanattributetype
no match broadcast,no match multicast,orno
match unicast
.
b. CEVLANID:ThisaddsthecustomeredgeVLANIDtothematchcriteriaofthe
map.Tosetthisvalue,type
matchce-vlan-id <0-4094>.Toremovethis
attributefromthematchcriteria,type
no match ce-vlan-id.
c. CEVLANPriority:ThisaddsthecustomeredgeVLANprioritytothematch
criteriaofthemap.Tosetthisvalue,type
matchce-vlan-pri <0-7>.Toremove
thisattributefromthematchcriteria,type
no match ce-vlan-pri.Arangeof
valuescanbespecifiedaspartofthiscommand.
d. Discard:Ifthisvalueisset,theNetVantadiscardsalltrafficthatmatchesthemaps
matchcriteria.Toenablediscardingtraffic,type
connect discard.Todisable,
type
no connect discard.Thisconnectiontakestheplaceoftheconnectionto
theEVC.
NOTE
IfthemapwaspreviouslyconnectedtoanEVC,itwillhavetobereconnected
aftertheno connect discardcommandisused.
e. DifferentiatedServicesCodePoint(DSCP):ThisaddstheInternetProtocolDSCPof
thecustomertraffictothematchcriteriaofthemap.Tosetthisvalue,type
match
