Total Access 5000 Business Services Deployment Guide
3-10 65K510DEP08-1A
Example #4
ThestepstoturnupasystemwithNet1asUplinkandNet2asDownlinkare:
#
configure terminal
(config)#node number 2
(config)#interface gigabit-ethernet 1/A/2
(configgig‐eth1/A/2)#downlink
(configgig‐eth1/A/2)#exit
(config)#exit
#
Provision the Gigabit-Ethernet Speed
ToprovisiontheGigabit‐Ethernetspeed,completethefollowing:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
interface gigabit-ethernet 1/A/1,
andpress
ENTERtoaccessthe GigE SMinslotAandtheNet1Configurationprompt.
IfslotBistheactiveSM,use1/B/1forthe<shelf/slot/port>syntax.
3. ProvisiontheGigabit‐Ethernetspeedbyperformingoneofthefollowingcommands:
•Type
speed 1000,andpressENTERtoconfigurethegigabitethernetfor1000Mbps
operation
•Type
speed auto,andpressENTERtoenabletheauto‐negotiationofspeed
•ThedefaultGigabit‐Ethernetspeedisauto.
•TheAutoNegotiationsettingontheTotalAccess5000shouldbeconsistent
withtheassociatedupstreamswitchport’sAutoNegotiationsetting.
•FormoreinformationonLACP,referto “AppendixA,LinkAggregation
Guide”.
4. Type
end,andpressENTERtoreturntotheEnableprompt.
