Appendix F, NetVanta Examples - Bandwidth Policer
65K510DEP08-1A F-15
Admin State
Thisattributeistheuser‐configurablestateofthepolicer.TableF‐12liststheavailableoptions.
Mode
Thisattributecontrolshowthepolicerisapplied.ApolicercanbeappliedtomultipleEVC
mapssimultaneouslyandthelistofEVCmapsitappliestoisdeterminedbythemodethatit
isconfiguredin.TableF ‐13liststheavailablemodes.
UNI
ThisattributeisavailableandmeaningfulonlyifthemodeisperUNI.Thepolicerisapplied
toallEVCmapsconnectedtoaspecificUNI.
EVC
ThisattributeisavailableandmeaningfulonlyifthemodeisperEVC.Thevalueisthename
oftheassociatedEVC.ThepolicerisappliedtoEVCmapsconnectedtothesameUNIand
connectedtoaspecificEVC.Itcanbewordedas“PerEVCperUNI.”
List of EVC-maps
EachpolicerentryliststheEVCmapsthatmatchthecriteriaandapolicingstatusforeach
EVCmap.AnEVCmapentrywithastatusof“Applied”indicatesalltrafficmatchedbythe
EVCmapissubjecttothebandwidthprofileofthepolicer.
CIR
TheCIRdefinestheaveragerateinkilobitpersecond(kbps)ofserviceframesuptowhichthe
networkdeliversserviceframesandmeetstheperformanceobjectivesoftheservice.Service
framesadmittedbytheCIRarecoloredgreen.
Table F-12. Policer State Options
Option Definition
Enabled Thepolicerisinservice,andtheprovisioningisappliedifthe
conditionsarevalid.
Disabled Thepolicerisnotinservice,andtheprovisioningisnotapplied.
Table F-13. Mode Options
Option Definition
NotApplied Thepolicerisnotapplied.
PerUNI ThepolicerisappliedtoallEVCmapsofaspecificUNIport.
PerEVC ThepolicerisappliedtoallEVCmapsassociatedwithaspecific
EVC.
Custom ThepolicerisappliedtooneormoreEVCmaps.
