Total Access 5000 Business Services Deployment Guide
2-12 65K510DEP08-1A
NOTE
TheAMIO2 ‐CH50PsupportstheCOMBOA2+24‐PortandRPOTS24‐Port
AccessModules.
AMIO2-CH64P Rear Panel
TheAMIO2‐CH64PcoverstwomoduleslotsontherearoftheTotalAccess5000Chassis.The
AMIO2‐CH64Pisdesignedtoholdtwostandardentry64‐pinmalechampconnectorcables.
Forstandardentry,the cableexitsthe90°connectorhoodonthepin1endofthemalechamp

connector.
NOTE
Push‐throughpanelsareprovidedwithfourCaptiveChampScrewsfor
installationoftwoconnectorstothepanel.Usetwoscrewsforeachconnector,
oneforthemountingbracket,thesecondtosecuretheconnectortothepanel.
TheCaptiveCham pScrewprovidedwiththecablemustbereplacedifitis
nota0.35inchscrew.
LMIO2-CH64B Rear Panel
TheLMIO2‐CH64Bisaninterconnectfortwolinemoduleslotsontherearofthechassis.The
LMIO2‐CH64Bmoduleprovidesmetallicaccessto32four‐wirecircuitsperaccessmodule
installedforamaximumof32four‐wirecircuits.Two64‐pinmale90°champconnectors
attachtothe
LMIO2‐CH64B,andprovideconnectionandstabilizationbetweenmodulesin
theTotalAccess5000Chassisandexternalcableconnectionsthatuse64‐pinconnectors.For
standardentry,thecableexitsthe90°connectorhoodonthepin1endofthemalechamp
connector.
LMIO2-CH50D Rear Panel
TheLMIO2‐CH50DisaninterconnectfortwolinemoduleslotsontherearoftheTotalAccess
5000Chassis.TheLMIO2‐CH50Dprovidesmetallicaccessto8four‐wirecircuitsperaccess
moduleinstalledforamaximumof16four‐wirecircuits.Two50‐pinmale90°champ
connectorsattach
totheLMIO2‐CH50D,andprovideconnectionandstabilizationbetween
modulesintheTotalAccess5000Chassisandexternalcableconnectionsthatuse50‐pin
connectors.Forstandardentry,thecableexitsthe90°connectorhoodonthepin1endofthe
malechampconnector.
LMIO2 HD DS1 Rear Panel
TheLMIO2HDDS1RearPanelisaninterconnectfortwolinemoduleslotsontherearofthe
TotalAccess5000Chassis.TheLMIO2HDDS1providesmetallicaccessto32four‐wire
circuitsperaccessmodule.Four2mmconnectorsprovideaccesstotheDSXloops.Theupper
connectors
providethetransmitpair,andthelowerconnectorsprovidethereceivepair.
