ADTRAN TA 5000 User Manual

Section 6, EoTDM Provisioning - Create an EFM Bonding Group
65K510DEP08-1A 6-9
Configure EFM Bonding Management Provisioning
TheNetVanta800InbandManagementconfigurationistiedtotheEFMbondinggroup.
Thus,whenaNetVantaisreplaced,theremotemanagementconfigurationispusheddownso
thattheNetVantaisimmediatelyremoteaccessiblewhenatleastoneDS3linksynchronizes.
NOTE
•Ifprovisioning the NetVanta 800locally,theTotalAccess5000overwrites
theIn bandmanagementprovisioningwhentheDS3portssynchronize
withtheDS3EFMaccessmodule.
•TheInbandmanagementoftheNetVanta 800isco nfiguredattheTotal
Access 5000, and pushed down to the NetVanta 800 as soon as
synchronizationisachievedononeofthelinksofthebondedgroup.
ToconfiguretheEFMbondinggroupmanagementprovisioning,completethefollowing:
1. FromtheEnableprompt,type
configure terminal,andpressENTERtoaccesstheGlo‐
balConfigurationprompt.
2. FromtheGlobalConfigurationprompt,type
interfaceefm-group <shelf/slot/
group>
,andpressENTERtoaccesstheEFMBondingGroupConfigurationprompt.
3. FromtheEFMGroupInte rface Configurationprompt,type
subtended-host ip
address A.B.C.D E.F.G.H
,andpressENTERtoprovisiontheNetVantaManagement
IPaddress(A.B.C.D)andsubnetmask(E.F.G.H).
4. FromtheEFMGroupInte rface Configurationprompt,type
subtended-host s-tag
<1-4094>
,andpressENTERtoprovisiontheNetVantaManagementVLAN.
5. FromtheEFMGroupInte rface Configurationprompt,type
subtended-host ip
default-gateway A.B.C.D
,andpressENTERtoprovisiontheNetVantaManagement
Gateway.
6. FromtheEFMGroupInte rface Configurationprompt,type
subtended-host ip
file-server default host A.B.C.D
,andpressENTERtoprovisiontheNetVanta800
ManagementTFTPserver.
7. FromtheEFMGroupInte rface Configurationprompt,type
subtended-host snmp-
server chassis-id WORD
,andpressENTERtoprovisiontheNetVantaSNMPsystem
name.
8. FromtheEFMGroupInte rface Configurationprompt,type
subtended-host snmp-
server community read-only WORD
,andpressENTERtoprovision theread‐only
SNMPcommunity.
9. FromtheEFMGroupInte rface Configurationprompt,type
subtended-host snmp-
server community read-write WORD
,andpressENTERtoprovisiontheread‐write
SNMPcommunity.
10. FromtheEFMGroupInterfaceConfigurationprompt,type
end,andpressENTERto
returntotheEnableprompt.
NOTE
Thisinformation is sent to the NetVanta 800 by wa y of an overhead
managementchannel.
