Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 111
System Operation and Configuration Chapter 4
state in which the Trip/Warn LED on the Communication Module and
Operator station blinks a red 3 long and 11 short blinking pattern.
Table 108 - Expansion Bus Trip Bit Function Detail— Control Trip Enable (Parameter 186)
To return to Ready/Run Mode, verify that the expansion bus cables are properly
plugged into the Bus In and Bus Out ports of all expansion modules. When all of
the expansion I/O modules’ status LEDs are solid green, reset the trip state of the
E300 relay by pressing the blue reset button on the Communication Module, via
network communication, with the internal web server of the EtherNet/IP
communication module, or by an assigned digital input.
Bit
1514131211109876543210 Function
X Test Trip Enable
XPTC Trip Enable
X DeviceLogix Trip Enable
X Operator Station Trip Enable
X Remote Trip Enable
X Blocked Start Trip Enable
X Hardware Fault Trip Enable
X Configuration Trip Enable
X Option Match Trip Enable
X Feedback Timeout Trip Enable
X Expansion Bus Trip Enable
Reserved
Reserved
X Nonvolatile Memory Trip Enable
XReady
Reserved

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
