Rockwell Automation Publication 193-UM015E-EN-P - October 2015 87
System Operation and Configuration Chapter 4
Analog I/O Expansion Module 2 Type (Parameter 230)
The E300 relay supports up to four additional Analog I/O expansion modules.
This parameter configures the Option Match feature for the Analog I/O
expansion module set to Analog Module 2. There is one type of Analog I/O
expansion module. Place the value of the expected Analog I/O expansion module
set to Analog Module 2 into Parameter 230. A value of (0) disables the Option
Match feature for this Analog I/O expansion module. A value of (1), “No Analog
I/O Expansion Module, makes the Analog I/O expansion module set to Analog
Module 2 not allowed on the Expansion Bus and prevents you from connecting
an Analog I/O expansion module set to Analog Module 2 to the E300 relay
system.
Table 41 - Analog I/O Expansion Module 2 Type (Parameter 230)
Analog I/O Expansion Module 3 Type (Parameter 231)
The E300 relay supports up to four additional Analog I/O expansion modules.
This parameter configures the Option Match feature for the Analog I/O
expansion module set to Analog Module 3. There is one type of Analog I/O
expansion module. Place the value of the expected Analog I/O expansion module
set to Analog Module 3 into Parameter 231. A value of (0) disables the Option
Match feature for this Analog I/O expansion module. A value of (1), “No Analog
I/O Expansion Module, makes the Analog I/O expansion module set to Analog
Module 3 not allowed on the Expansion Bus and prevents you from connecting
an Analog I/O expansion module set to Analog Module 3 to the E300 relay
system.
Table 42 - Analog I/O Expansion Module 3 Type (Parameter 231)
Code Description Analog I/O Expansion Module Cat. No.
0 Ignore
1
No Analog I/O Expansion Module (Analog I/O Expansion
Module Not Allowed)
2 3 Universal Analog Inputs / 1 Analog Output 193-EXP-AIO-31
Code Description Analog I/O Expansion Module Cat. No.
0 Ignore
1
No Analog I/O Expansion Module (Analog I/O Expansion
Module Not Allowed)
2 3 Universal Analog Inputs / 1 Analog Output 193-EXP-AIO-31
