440 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 6 Protective Trip and Warning Functions
Contactor Feedback Warning
The E300 relay provides a Contactor Feedback warning indication if:
No trip currently exists
The Operating Mode program does not receive a contactor feedback
signa
l before the Feedback Timeout (Parameter 213)
If the E300 relay warns on a Contactor Feedback, the following occurs:
The TRIP/WARN LED flashes a yellow 3-long / 10-short blink pattern
Bit 9 in Control Warning Status (Parameter 13) sets to 1
Bit 1 in Device Status 0 (Parameter 20) sets to 1
Any relay outputs configured as a Warning Alarm closes
Expansion Bus Fault
See Expansion Bus Fault in Chapter 4 for more information on Expansion Bus
Trip a nd Warn i ng .
Nonvolatile Storage Fault
The E300 relay continuously monitors the status of its nonvolatile storage. The
E300 relay issues a nonvolatile storage fault trip if there is an issue with its
IMPORTANT
The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
Output PT00 Protection Fault Action (Parameter 304)
Output PT00 Protection Fault Value (Parameter 305)
Output PT01 Protection Fault Action (Parameter 310)
Output PT01 Protection Fault Value (Parameter 311)
Output PT02 Protection Fault Action (Parameter 316)
Output PT02 Protection Fault Value (Parameter 317)
Output Digital Module 1 Protection Fault Action (Parameter 322)
Output Digital Module 1 Protection Fault Value (Parameter 323)
Output Digital Module 2 Protection Fault Action (Parameter 328)
Output Digital Module 2 Protection Fault Value (Parameter 329)
Output Digital Module 3 Protection Fault Action (Parameter 334)
Output Digital Module 3 Protection Fault Value (Parameter 335)
Output Digital Module 4 Protection Fault Action (Parameter 340)
Output Digital Module 4 Protection Fault Value (Parameter 342)
