Allen-Bradley E300 User Manual

500 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 8 Metering and Diagnostics
Operator Station ID
Operator Station ID (Parameter 25) identifies which specific Operator Station is
present on the Expansion Bus of the E300 relay system.
Table 440 - Operator Station ID (Parameter 25)
Expansion Digital Module ID
Expansion Digital Module ID (Parameter 26) identifies which specific
Expansion Digital Modules are present on the Expansion Bus of the E300 relay
system.
Table 441 - Expansion Digital Module ID (Parameter 26
Default Value 0
Range
0 = Unknown
1 = None
2 = 193-EOS-SCS
3 = 193-EOS-SDS
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units
Bit
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0 Function
0 0 0 0 Unknown
Digital Module 1
0001None
0 0 1 0 193-EXP-DIO-42-24D
0 0 1 1 193-EXP-DIO-42-120
0 1 0 0 193-EXP-DIO-42-240
0000 Unknown
Digital Module 2
0001 None
0010 193-EXP-DIO-42-24D
0011 193-EXP-DIO-42-120
0100 193-EXP-DIO-42-240
0000 Unknown
Digital Module 3
0001 None
0 0 1 0 193-EXP-DIO-42-24D
0 0 1 1 193-EXP-DIO-42-120
0 1 0 0 193-EXP-DIO-42-240
0000 Unknown
Digital Module 4
0001 None
0 0 1 0 193-EXP-DIO-42-24D
0 0 1 1 193-EXP-DIO-42-120
0 1 0 0 193-EXP-DIO-42-240

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
