Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 631
Appendix B
Parameter List
Overview
This appendix lists all accessible parameters of the E300™ Electronic Overload
Relay in numerical order.
The setting range for each parameter is provided to assist especially for
applications where it is desirable to set values from a logic controller via a network
connection.
Information values provided include the following:
Value Function
Setting Range Indicated as raw numerical values.
Scale Factor Indicate the decimal precision associated with each parameter. This must be given close attention when writing or
reading values.
Default Indicate the factory pre-programmed values.
Group
Param
No.
Parameter Name Device Profile Tag Name Description Type
Data Size
(bytes)
Scale
Factor
Min Max Default Units
Device Monitor 1 ThermUtilizedPct I.PercentTCU % Thermal
Capacity Used
USINT 1 1 0 100 0 %
2 OLTimeToTrip Time until an
overload trip
UINT 2 1 0 9999 0
Seconds
3 OLTimeToReset Time until OL trip
can be reset
UINT 2 1 0 9999 0
Seconds
4 TripStsCurrent I.Protection.OverloadTrip
I.Protection.PhaseLossTrip
I.Protection.GroundFaultCurrentTrip
I.Protection.StallTrip
I.Protection.JamTrip
I.Protection.UnderloadTrip
I.Protection.CurrentImbalanceTrip
I.Protection.L1UnderCurrentTrip
I.Protection.L2UnderCurrentTrip
I.Protection.L3UnderCurrentTrip
I.Protection.L1OverCurrentTrip
I.Protection.L2OverCurrentTrip
I.Protection.L3OverCurrentTrip
I.Protection.L1LineLossTrip
I.Protection.L2LineLossTrip
I.Protection.L3LineLossTrip
Trip Status bits for
Current
UINT 2 1 Bit0= OverloadTrip
Bit1= PhaseLossTrip
Bit2= GroundFaultTrip
Bit3= StallTrip
Bit4= JamTrip
Bit5= UnderloadTrip
Bit6= CurrentImbalTrip
Bit7= L1UnderCurrTrip
Bit8= L2UnderCurrTrip
Bit9= L3UnderCurrTrip
Bit10= L1OverCurrenTrip
Bit11= L2OverCurrenTrip
Bit12= L3OverCurrenTrip
Bit13= L1LineLossTrip
Bit14= L2LineLossTrip
Bit15= L3LineLossTrip
0
5 TripStsVoltage I.Protection.UnderVoltageTrip
I.Protection.OverVoltageTrip
I.Protection.VoltageImbalanceTrip
I.Protection.PhaseRotationMismatchTrip
I.Protection.UnderFrequencyTrip
I.Protection.OverFrequencyTrip
Trip Status bits for
Voltage
UINT 2 1 Bit0= UnderVoltageTrip
Bit1= OvervoltageTrip
Bit2= VoltageUnbalTrip
Bit3= PhaseRotationTrp
Bit4= UnderFreqTrip
Bit5= OverFreqTrip
0

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
