Allen-Bradley E300 User Manual

50 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 2 Installation and Wiring
Control Module
Figure 40 - E300 Control Module Terminal Designations
193-EIOGP-42- _ _ _
193-EIOGP-22- _ _ _
Sensing Module Latch
Power / PTC
Terminals
Expansion Bus Connector
Relay / Ground Fault
Terminals
R13
R14
S1
S2
A1
A1
A2
IN2
IN3
IT1
IT2
R13
R14
S1
S2
193-EIO-63- _ _ _
193-EIO-43- _ _ _
R13
R14
R23
R24
A1
A1
A2
IN2
IN3
IN4
IN5
R13
R14
R23
R24
A1
A1
A2
IN2
IN3
A1
A1
A2
IT1
IT2
Input / Output
Terminals
Communication
Module Latch
IN1
IN0
A2
A1
R04
R03

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
