Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 515
Metering and Diagnostics Chapter 8
L1 Real Power
L1 Real Power (Parameter 64) reports the real power for line 1 in kW or MW
depending on the configuration value for Power Scale (Parameter 377). When
Voltage Mode (Parameter 352) is set to any Delta base setting, L1 Real Power is
set to 0.
Table 478 - L1 Real Power (Parameter 64)
L2 Real Power
L2 Real Power (Parameter 65) reports the real power for line 2 in kW or MW
depending on the configuration value for Power Scale (Parameter 377). When
Voltage Mode (Parameter 352) is set to any Delta base setting, L2 Real Power is
set to 0.
Table 479 - L2 Real Power (Parameter 65)
L3 Real Power
L3 Real Power (Parameter 66) reports the real power for line 3 in kW or MW
depending on the configuration value for Power Scale (Parameter 377). When
Voltage Mode (Parameter 352) is set to any Delta base setting, L3 Real Power is
set to 0. When Single or Three Phase (Parameter 176) is set to Single Phase, L3
Real Power is set to 0.
Default Value 0.000
Minimum Value -2000000.000
Maximum Value 2000000.000
Parameter Type DINT
Size (Bytes) 4
Scaling Factor 1000
Units kW or MW
Default Value 0.000
Minimum Value -2000000.000
Maximum Value 2000000.000
Parameter Type DINT
Size (Bytes) 4
Scaling Factor 1000
Units kW or MW

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
