478 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 7 Commands
Table 418 - Config Preset (Parameter 164)
The following pages list the available configuration presets and the values for the
associated pre-configured configuration values.
Factory Defaults
When the Factory Defaults configuration preset command is selected, the E300
relay restores all configuration parameters back to their original factory default
values.
Figure 212 - Factory Default Values
Default Value 0 = Ready
Range 0 = Ready
1 = Factory Defaults
Parameter Type USINT
Size (Bytes) 1
Scaling Factor 1
Units
No. Parameter Name Default
Value
Units No. Parameter Name Default
Value
Units No. Parameter Name Default
Value
Units
139 TripHistoryMaskI 0xFFFF 304 OutPt00PrFltAct Goto Value 428 Screen1Param1 1
140 TripHistoryMaskV 0x003F 305 OutPt00PrFltVal Open 429 Screen1Param2 50
141 TripHistoryMaskP 0x0FFF 306 OutPt00ComFltAct Goto Value 430 Screen2Param1 2
142 TripHistoryMaskC 0x27FF 307 OutPt00ComFltVal Open 431 Screen2Param2 3
143 TripHistoryMaskA 0x0FFF 308 OutPt00ComIdlAct Goto Value 432 Screen3Param1 51
145 WarnHistoryMaskI 0xFFFF 309 OutPt00ComIdlVal Open 433 Screen3Param2 52
146 WarnHistoryMaskV 0x003F 310 OutPt01PrFltAct Goto Value 434 Screen4Param1 38
147 WarnHistoryMaskP 0x0FFF 311 OutPt01PrFltVal Open 435 Screen4Param2 39
148 WarnHistoryMaskC 0x1FFF 312 OutPt01ComFltAct Goto Value 436 DisplayTimeout 300 Seconds
149 WarnHistoryMaskA 0x0FFF 313 OutPt01ComFltVal Open 437 InAnMod1Ch00Type Disable
171 FLASetting 0.50 Amps 314 OutPt01ComIdlAct Goto Value 438 InAMod1Ch0Format Eng Units
172 TripClass 10 315 OutPt01ComIdlVal Open 439 InAMod1C0TmpUnit Degrees C
173 OLPTCResetMode Automatic 316 OutPt02PrFltAct Goto Value 440 InAMod1C0FiltFrq 17 Hz
174 OLResetLevel 75 %TCU 317 OutPt02PrFltVal Open 441 InAMod1C0OpCktSt Upscale
175 OLWarningLevel 85 %TCU 318 OutPt02ComFltAct Goto Value 442 InAnMod1Ch0RTDEn 3-Wire
176 SingleOrThreePh Three Phase 319 OutPt02ComFltVal Open 443 InAMod1C0TripDly 1.0 Seconds
177 FLA2Setting 0.50 Amps 320 OutPt02ComIdlAct Goto Value 444 InAMod1C0TripLvl 0
183 TripEnableI 0x0003 321 OutPt02ComIdlVal Open 445 InAMod1C0WarnLvl 0
184 TripEnableV 0 322 OutDig1PrFltAct Goto Value 446 InAnMod1Ch01Type Disable
185 TripEnableP 0 323 OutDig1PrFltVal Open 447 InAMod1Ch1Format Eng Units
186 TripEnableC 0x20C9 324 OutDig1ComFltAct Goto Value 448 InAMod1C1TmpUnit Degrees C
187 TripEnableA 0 325 OutDig1ComFltVal Open 449 InAMod1C1FiltFrq 17 Hz
189 WarningEnableI 0 326 OutDig1ComIdlAct Goto Value 450 InAMod1C1OpCktSt Upscale
190 WarningEnableV 0 327 OutDig1ComIdlVal Open 451 InAnMod1Ch1RTDEn 3-Wire
191 WarningEnableP 0 328 OutDigp2PrFltAct Goto Value 452 InAMod1C1TripDly 1.0 Seconds
192 WarningEnableC 0 329 OutDig2PrFltVal Open 453 InAMod1C1TripLvl 0
193 WarningEnableA 0 330 OutDig2ComFltAct Goto Value 454 InAMod1C1WarnLvl 0
