78 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 4 System Operation and Configuration
Ready Mode
Ready Mode is a standby mode for the E300 relay in which the relay is ready to
help protect an electric motor and no electrical current has been detected. You
can modify configuration parameters, update firmware, and issue commands if
the appropriate security policies are enabled. The Power LED on the
Communication Module and Operator Stations flash green and bit 14 in Device
Status 0 (Parameter 20) is set to 1 when the device is in Ready Mode.
Table 26 - Ready Mode Bit Function Detail — Device Status 0 (Parameter 20)
Run Mode
Run Mode is an active mode for the E300 relay in which the relay is sensing
electrical current and is actively protecting an electric motor. Only non-motor
protection configuration parameters can be modified if the appropriate security
policies are enabled. The Power LED on the Communication Module and
Operator Stations is solid green and bits 3, 4, and/or 5 in Device Status 0
(Parameter 20) are set to 1 when the device is in Run Mode.
Bit
1514131211109876543210 Function
X Trip Present
X Warning Present
X Invalid Configuration
X Current Present
X GFCurrent Present
X Voltage Present
X Emergency Start Enabled
X DeviceLogix Enabled
X Feedback Timeout Enabled
X Operator Station Present
X Voltage Sensing Present
X Intern Ground Fault Sensing Present
X Extern Ground Fault Sensing Present
XPTC Sensing
XReady
Reserved
