364 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 6 Protective Trip and Warning Functions
• L3 Line Loss Warning is enabled
• L3 Line Loss is activated via the appropriately programmed digital input
(see
Input Assignments, Parameters 196…201, in Chapter
4)
• Line Loss Inhibit Timer has expired
• L3 Pe
rcent FLA (Parameter 49) is equal to 0%
When
the L3 Line Loss Warning conditions are satisfied, the:
• TRIP/WARN LED flashes a yellow 16-short blink pattern
• Bit 15 in Current Warning Status (Parameter 10) sets to 1
• Bit 1 in Device Status 0 (Parameter 20) sets to 1
• Any relay outputs configured as a Warning Alarm close
Voltage-based Protection
The E300 relay can digitally monitor the voltage supplied to an electric motor to
help protect against poor voltage quality. You can prevent a contactor from
energizing if the voltage is either too high, too low, or wrong rotation. The
following E300 Sensing Modules provide voltage monitoring capabilities.
Table 286 - Voltage Capabilities
This voltage information is used for the following protective trip and warning
functions:
• Undervoltage trip/warning
• Overvoltage trip/warning
• Voltage imbalance trip/warning
• Phase rotation mismatch trip
• Under frequency trip/warning
• Over frequency trip/warning
Voltage Trip Enable (Parameter 184) and Voltage Warning Enable (Parameter
190) are used to enable the respective voltage-based protective trip and warning
functions.
The L3 Line Loss Warning function does not include a time delay feature. Once
the Line Loss Inhibit Timer has expired, the L3 Line Loss Warning indication is
instantaneous.
Catalog Number Measurement Method L-L Voltage Trip/Warning Range
193-ESM-VIG-__-__ Internal 20…800V
592-ESM-VIG-__-__ Internal 20…800V
193-ESM-VIG-30A-CT External 20…6500V
