Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 511
Metering and Diagnostics Chapter 8
L3-L1 Voltage
L3-L1 Voltage (Parameter 55) reports the voltage in volts in reference to the T3
and T1 power terminals of the E300 relay Sensing Module.
Table 468 - L3-L1 Voltage (Parameter 55)
Average L-L Voltage
Average L-L Voltage (Parameter 56) reports the average voltage of the monitored
L-L voltages. When Single or Three Phase (Parameter 176) is set to Three Phase,
Average L-L Voltage is calculated as follows:
Average L-L Voltage = (L1-L2 Voltage + L2-L3 Voltage + L3-L1 Voltage) / 3
When Single or Three Phase (Parameter 176) is set to Single Phase, Average L-L
Voltage is calculated as follows:
Average L-L Voltage = (L1-L2 Voltage + L2-L3 Voltage) / 2
Table 469 - Average L-L Voltage (Parameter 56)
L1-N Voltage
L1-N Voltage (Parameter 57) reports the voltage in volts in reference to the T1
power terminal of the E300 relay Sensing Module.
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts
Default Value 0.0
Minimum Value 0.0
Maximum Value 6553.5
Parameter Type UINT
Size (Bytes) 2
Scaling Factor 10
Units Volts

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
