Output Pt02 Assignment (Parameter 204)
Output Pt02 Assignment (Parameter 204) allows you to assign this relay output
for the following functions:
Table 54 - Output Pt02 Assignment (Parameter 204)
Table 55 - Activate FLA2 with Output Relay (Parameter 209)
Activate FLA2 with Output Relay (Parameter 209) allows you to activate the
value in FLA2 Setting (Parameter 177) for the current-based protection
algorithms when the assigned output relay is in an energized state.
Table 56 - Activate FLA2 with Output Relay (Parameter 209)
Output Relay Configuration
States
When assigned as a Normal/General Purpose Relay or Control/Control & Trip
Relay, you can configure the E300 relay's output relays to go to a specific safe state
when one of following events occur:
• Protection Fault Mode - when a trip event occurs
V
a
l
u
e
A
ss
ign
m
en
t
D
es
cri
p
ti
on
0 Normal Function as a relay output
1Trip Relay
Function as a normally closed contact until the E300 relay is in a tripped state in which the relay opens. The Trip
Relay remains open until a trip reset is issued.
2Control Relay
Function as a combination Normal and Trip Relay. The Control Relay is in a normally open state until the relay is
commanded to close by communication or via a DeviceLogix program. When the E300 relay enters into a tripped
state, the Control Relay opens and remains open until a trip reset is issued.
3Trip Alarm
Function as a normally open contact until the E300 relay is in a tripped state in which the relay closes. The Trip
Alarm remains closed until a trip reset is issued.
4 Warning Alarm
Function as a normally open contact until the E300 relay is in a protection warning state in which the relay closes.
The Warning Alarm remains closed until the protection warning clears.
5 Monitor L1 Trip Relay
(1)
Function as a normally closed contact until the E300 relay is in a tripped state for a L1 Under Current, L1 Over
Current, or L1 Line Loss in which the relay opens. The Trip Relay remains open until a trip reset is issued.
6 Monitor L2 Trip Relay
(1)
Function as a normally closed contact until the E300 relay is in a tripped state for a L2 Under Current, L2 Over
Current, or L2 Line Loss in which the relay opens. The Trip Relay remains open until a trip reset is issued.
7 Monitor L3 Trip Relay
(1)
Function as a normally closed contact until the E300 relay is in a tripped state for a L3 Under Current, L3 Over
Current, or L3 Line Loss in which the relay opens. The Trip Relay remains open until a trip reset is issued.
8Monitor L1 Control Relay
(1)
Function as a combination Normal and Trip Relay. The Control Relay is in a normally open state until the relay is
commanded to close by communication or via a DeviceLogix program. When the E300 relay is in a tripped state for
a L1 Under Current, L1 Over Current, or L1 Line Loss, the relay opens. The Control Relay remains open until a trip
reset is issued.
9Monitor L2 Control Relay
(1)
Function as a combination Normal and Trip Relay. The Control Relay is in a normally open state until the relay is
commanded to close by communication or via a DeviceLogix program. When the E300 relay is in a tripped state for
a L2 Under Current, L2 Over Current, or L2 Line Loss, the relay opens. The Control Relay remains open until a trip
reset is issued.
10 Monitor L3 Control Relay
(1)
Function as a combination Normal and Trip Relay. The Control Relay is in a normally open state until the relay is
commanded to close by communication or via a DeviceLogix program. When the E300 relay is in a tripped state for
a L3 Under Current, L3 Over Current, or L3 Line Loss, the relay opens. The Control Relay remains open until a trip
reset is issued.
(1) Requires Control Module firmware v3.000 or higher
Value Description
0 Disable
1 Pt00 Output
2 Pt01 Output
3 Pt02 Output
