Allen-Bradley E300 User Manual

Rockwell Automation Publication 193-UM015E-EN-P - October 2015 523
Metering and Diagnostics Chapter 8
kWh 10
-3
kWh 10
-3
(Parameter 84) reports a component of total real energy (kWh).
Multiply this value by 10
-3
and add to the other kWh parameters.
Represents 000,000,000,000. XXX kW h
Table 498 - kWh x 10
-3
(Parameter 84)
kVARh Consumed 10
9
kVARh Consumed 10
9
(Parameter 85) reports a component of total reactive
energy consumed (kVARh). Multiply this value by 10
9
and add to the other
kVARh Consumed parameters.
Represents XXX,000,000,000.000 kVARh
Table 499 - kVARh Consumed x 10
9
(Parameter 85)
kVARh Consumed 10
6
kVARh Consumed 10
6
(Parameter 86) reports a component of total reactive
energy consumed (kVARh). Multiply this value by 10
6
and add to the other
kVARh Consumed parameters.
Represents 000,XXX,000,000.000 kVARh
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units
Default Value 0
Minimum Value -999
Maximum Value 999
Parameter Type INT
Size (Bytes) 2
Scaling Factor 1
Units

Allen-Bradley E300 Specifications

General

Type	Electronic Overload Relay
Mounting	DIN Rail or Panel Mount
Protection Class	IP20
Voltage Range	24…690 V AC/DC
Communication Options	EtherNet/IP, DeviceNet
Protection	Overload, phase loss, ground fault
Operating Temperature	-20°C to 60°C
