290 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 5 Operating Modes
Figure 193 - Two-speed Starter (Local I/O) – Three-wire Control DeviceLogix Program, Part C
Timing Diagram
Figure 194 - Two-speed Starter (Local I/O) – Three-wire Control Timing Diagram
Two-speed Starter (Network & Operator Station)
The E300 relay’s Operating Mode Two Speed Starter (Network& Operator
Station) (Parameter 195 = 15) in Remote control mode uses network tags
LogicDefinedPt00Data in Output Assembly 144 to control Relay 0, which
Run Fast
Trip Event
Stop
Fast (Relay 0)
Trip Status
Trip Reset
Slow (Relay 1)
Run Slow
