Rockwell Automation Publication 193-UM015E-EN-P - October 2015 123
System Operation and Configuration Chapter 4
The E300 Analog I/O Expansion Module input channel scan time is 1242 ms
(1024+153+65).
Analog Output Channel
The E300 Analog I/O Expansion Module output channel update rate is 10 ms.
Analog Module 1
Analog Module 1 – Input Channel 00 Type
Analog Module 1 – Input Channel 00 Type (Parameter 437) defines the type of
analog signal that Input Channel 00 of Analog Module 1 monitors.
Table 130 - Analog Module 1 – Input Channel 00 Type (Parameter 437)
Analog Module 1 – Input Channel 00 Format
Analog Module 1 – Input Channel 00 Format (Parameter 438) defines the data
format for how the analog reading is reported.
Value Assignment Description
0 Disabled Disable the analog input
1 4To20mA Read an analog current signal from 4…20 mA
2 0To20mA Read an analog current signal from 0…20 mA
3 0To10Volts Read an analog voltage signal from 0…10 V DC
4 1To5Volts Read an analog voltage signal from 1…5 V DC
5 0To5Volts Read an analog voltage signal from 0…5 V DC
6 100Pt385 Read a 100 Ω Pt 385 RTD Sensor
7 200Pt385 Read a 200 Ω Pt 385 RTD Sensor
8 500Pt385 Read a 500 Ω Pt 385 RTD Sensor
9 1000Pt385 Read a 1000 Ω Pt 385 RTD Sensor
10 100Pt3916 Read a 100 Ω Pt 3916 RTD Sensor
11 200Pt3916 Read a 200 Ω Pt 3916 RTD Sensor
12 500Pt3916 Read a 500 Ω Pt 3916 RTD Sensor
13 1000Pt3916 Read a 1000 Ω Pt 3916 RTD Sensor
14 10Cu426 Read a 10 Ω Cu 426 RTD Sensor
15 100Ni618 Read a 100 Ω Ni 618 RTD Sensor
16 120Ni672 Read a 120 Ω Ni 672 RTD Sensor
17 604NiFe518 Read a 604 Ω NiFe 518 RTD Sensor
18 150ohm Read a resistance signal from 0…150 Ω
19 750ohm Read a resistance signal from 0…750 Ω
20 3000ohm Read a resistance signal from 0…3000 Ω
21 6000ohm
Read a resistance signal from 0…6000 Ω. This setting
can be used with PTC and NTC sensors.
