124 Rockwell Automation Publication 193-UM015E-EN-P - October 2015
Chapter 4 System Operation and Configuration
Table 131 - Analog Module 1 – Input Channel 00 Format (Parameter 438)
Analog Module 1 – Input Channel 00 Temperature Unit
Analog Module 1 – Input Channel 00 Temperature Unit (Parameter 439)
defines the temperate unit for RTD sensor readings.
Table 132 - Analog Module 1 – Input Channel 00 Temperature Unit (Parameter 439)
Analog Module 1 – Input Channel 00 Filter Frequency
Analog Module 1 – Input Channel 00 Filter Frequency (Parameter 440) defines
update rate for the input channels of the analog module.
Table 133 - Analog Module 1 – Input Channel 00 Filter Frequency (Parameter 440)
Analog Module 1 – Input Channel 00 Open Circuit State
Analog Module 1 – Input Channel 00 Open Circuit State (Parameter 441)
defines what the input channel reports when the input channel has an open
circuit. Open circuit detection is always enabled for this input channel.
Table 134 - Analog Module 1 – Input Channel 00 Open Circuit State (Parameter 441)
Analog Module 1 – Input Channel 00 RTD Type Enable
Analog Module 1 – Input Channel 00 RTD Type Enable (Parameter 442)
defines the type of RTD to monitor when the input channel type is configured to
scan an RTD sensor.
Value Assignment Description
0 EngUnits Engineering Units (mA, V, °C, °F, or Ω)
1 EngUnitsTimes10 Engineering Units x 10 (mA, V, °C, °F, or Ω)
2 RawProportional Raw / Proportional (-32768…+32767)
3 ScaledForPID Scaled for PID (0…16383)
Value Assignment Description
0 DegreesC Report RTD Temperature Data in °C
1 DegreesF Report RTD Temperature Data in °F
Value Assignment Description
0 17 Hz Analog to Digital Conversion Update Frequency of 17 Hz
1 4 Hz Analog to Digital Conversion Update Frequency of 4 Hz
2 62 Hz Analog to Digital Conversion Update Frequency of 62 Hz
3 470 Hz Analog to Digital Conversion Update Frequency of 470 Hz
Value Assignment Description
0 Upscale Reports the high limit of the input channel type
1 Downscale Reports the low limit of the input channel type
2 Zero Reports zero
