Rockwell Automation Publication 193-UM015E-EN-P - October 2015 77
Chapter 4
System Operation and Configuration
Introduction
This chapter provides instructions about how to operate and configure an E300™
Electronic Overload Relay system. This chapter includes settings for Device
Modes, Option Match, Security Policy, I/O Assignments, Expansion Bus Fault,
Emergency Start, and an introduction to Operating Modes.
Device Modes
The E300 relay has five device modes to validate configuration of the device and
limit when you can configure the E300 relay, perform a firmware update, and
issue commands.
• Administration Mode
• Ready Mode
• Run Mode
• Te st Mo d e
• Invalid Configuration Mode
Administration Mode
Administration Mode is a maintenance mode for the E300 relay that allows you
to configure parameters, modify security policies, enable web servers (see
page 568
to enable the EtherNet/IP web server), perform firmware updates, and
issue commands.
Follow these steps to enter into Administration Mode:
1. Set the rotary dials on the E300 Communication Module to the following
values
– For EtherNet/IP set the rotary dials to 0-0-0
– For DeviceNet set the rotary dials to 7-7
2. Cycle power on the E300 relay
Aft
er commissioning activities and maintenance tasks are completed, return the
E300 relay
back to Ready or Run Mode by setting the rotary dials of the E300
communication module back to its previous positions and then cycle power.
