Rockwell Automation Publication 193-UM015E-EN-P - October 2015 433
Protective Trip and Warning Functions Chapter 6
Start Inhibit Protection
This protective function allows you to limit the number of starts in a given time
period and limit the operating hours for an electric motor. A start is defined as
the E300 relay sensing a transition in current from 0 A to 30% of the minimum
FLA rating of the device. The Blocked Start protective function is set by Starts
Per Hour (Parameter 205) and/or Starts Interval (Parameter 206).
Blocked Start Trip
The E300 relay trips with a blocked start trip indication if:
No trip currently exists
Blocked Start Trip is enabled
The nu
mber of starts within the past hour equals the value set in Starts Per
Hou
r (Parameter 205)
The t
ime between starts is less than the value set in Starts Interval
(Paramete
r 206)
If the E300 relay trips on a blocked start trip, the following occurs:
The TRIP/WARN LED flashes a red 3-long / 6-short blink pattern
Bit 5 in
Control Trip Status (Parameter 7) sets to 1
Bit 0 in Device Status 0 (Parameter 20) sets to 1
Any relay outputs configured as a Trip Relay open
Any relay outputs configured as a Control Relay open
IMPORTANT
The Protection Fault State of Relay 0, Relay 1, Relay 2, Digital Module 1 Output
Relays, Digital Module 2 Output Relays, Digital Module 3 Output Relays, and
Digital Module 4 Output Relays are defined by the respective parameters:
Output PT00 Protection Fault Action (Parameter 304)
Output PT00 Protection Fault Value (Parameter 305)
Output PT01 Protection Fault Action (Parameter 310)
Output PT01 Protection Fault Value (Parameter 311)
Output PT02 Protection Fault Action (Parameter 316)
Output PT02 Protection Fault Value (Parameter 317)
Output Digital Module 1 Protection Fault Action (Parameter 322)
Output Digital Module 1 Protection Fault Value (Parameter 323)
Output Digital Module 2 Protection Fault Action (Parameter 328)
Output Digital Module 2 Protection Fault Value (Parameter 329)
Output Digital Module 3 Protection Fault Action (Parameter 334)
Output Digital Module 3 Protection Fault Value (Parameter 335)
Output Digital Module 4 Protection Fault Action (Parameter 340)
Output Digital Module 4 Protection Fault Value (Parameter 342)
